WNMG 080408 Carbide Inserts

Name: WNMG 080408 Carbide Inserts
Brand: PRYSM GLOBAL TOOLING SOLUTIONS
Price: 270 INR
Availability: InStock

Price 270 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

WNMG 080408 Carbide Inserts Specification

Cutting Speed
150-400 m/min (depending on workpiece and grade)

Length
Approx. 8 mm (side length, varies by spec)

Tool Type
Carbide Insert

Cutting Accuracy
High Precision

Cutting Force
Low to Medium

Cutter Type
Indexable Insert

Material
Tungsten Carbide

Features
High Wear Resistance, Multiple Cutting Edges, Durable

Operate Method
Clamped in Tool Holder

Drill Bits Types
Turning Insert

Cutting Capacity
General Purpose, Suitable for Medium and Rough Machining

Hardness
89-92 HRA (depends on grade)

Coating Type
CVD/PVD

Coating
TiN / TiAlN / Multilayer (depends on manufacturer)

Shape
WNMG (Trigon, 80 with Negative Rake)

Machine Type
CNC Lathe, Conventional Lathe

Operation Type
External Turning, Facing

Diameter
8 mm (Insert Size Code: 080408)

Processing Type
CNC Machining / Turning

Number of Cutting Edges
6

Insert Thickness
4.76 mm

Package Quantity
10 Pieces per Box (typical)

Corner Radius
0.8 mm

ISO Code
WNMG 080408

Chipbreaker Type
General, available in multiple options

Grade Availability
Multiple carbide grades available

Applicable Material
Steel, Stainless Steel, Cast Iron, and Non-ferrous Metals

Heat Resistance
Up to 1000C (depending on coating and grade)

Usage
External turning and profiling applications

WNMG 080408 Carbide Inserts Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Pieces Per Month

Delivery Time
10 Days

About WNMG 080408 Carbide Inserts

Unlock stellar productivity and capitalise on the best that carbide technology offers with WNMG 080408 Carbide Inserts. Engineered for uncommon performance, these inserts are tailored for external turning and profiling operations on steel, stainless steel, cast iron, and non-ferrous metals. With an impressive six cutting edges per insert and a durable tungsten carbide build, they jump on challenging tasks while delivering high wear resistance and precision. Multiple grade and coating options provide adaptability, while heat resistance up to 1000C ensures consistent output. Supplied in boxes of 10 pieces, these inserts promise long tool life and cost efficiency for manufacturers, suppliers, and traders throughout India.

Precision Turning for Unmatched Versatility

WNMG 080408 Carbide Inserts are designed to excel in external turning, facing, and profiling applications. Their trigon (80 negative rake) geometry and robust chipbreaker make them suitable for both medium and rough machining, across CNC and conventional lathes. Users benefit from high hardness (up to 92 HRA), multiple cutting edges, and excellent heat resistance-delivering superior results across a range of ferrous and non-ferrous materials. The inserts guarantee accurate machining and extended tool life in CNC environments.

Supply Capability and Export Strengths

Our supply ability for WNMG 080408 Carbide Inserts meets high-volume industrial demand, ensuring reliable delivery throughout major export markets such as South Asia, the Middle East, and Europe. Each set is meticulously packaged-typically 10 inserts per box-to protect product integrity during transportation. With competitive list prices and prompt shipping methods, we are well-equipped to satisfy the procurement needs of manufacturers, traders, and suppliers seeking dependable and timely carbide insert solutions.

FAQ's of WNMG 080408 Carbide Inserts:

Q: How do WNMG 080408 Carbide Inserts benefit external turning and profiling operations?

A: These inserts offer high wear resistance, six cutting edges for extended use, and precise machining capability, making them ideal for both medium and rough machining in external turning and profiling applications.

Q: What materials can WNMG 080408 Carbide Inserts cut efficiently?

A: WNMG 080408 Carbide Inserts are suitable for processing steel, stainless steel, cast iron, and non-ferrous metals, offering flexibility across a variety of machining tasks.

Q: Where are these carbide inserts typically used?

A: They are widely utilised in CNC lathes and conventional lathes for machining, turning, and facing operations in manufacturing, engineering, tooling, and metalworking industries.

Q: When should different grades or coatings be selected for these inserts?

A: Grade selection depends on the specific material being machined, desired cutting speed, and heat resistance requirements, while coating choice (TiN, TiAlN, Multilayer) enhances performance in various operating conditions.

Q: What is the packaging detail for WNMG 080408 Carbide Inserts?

A: Typically, these inserts are supplied as 10 pieces per box, providing secure packaging to preserve quality during delivery and transportation.

Q: How do I install or operate these inserts correctly?

A: The inserts are designed to be clamped securely in compatible tool holders for use in CNC or conventional lathes, ensuring stable and accurate operation.
